4CFM 1/3HP AC Vacuum Pump Kit w/ Manifold Gauge Leak Detector R134a

4 CFM 1/3 HP AC Vacuum Pump Kit with Manifold Gauge & Leak Detector HVAC Vacuum Pump Kit for AC Recharge, Refrigerant Evacuation & System Diagnostics Complete Kit / 4 CFM Fast Evacuation / Manifold Gauge / Leak Detector / ETL Listed

This HVAC vacuum pump kit is designed for AC system evacuation, refrigerant recharge, and leak detection. The AC vacuum pump kit and manifold gauge set provides reliable performance for automotive AC, HVAC service, refrigerant recharge, air conditioning repair, and system diagnostics, helping technicians complete jobs faster and more efficiently.

Key Features

• Complete HVAC Vacuum Pump Kit for AC Recharge: Includes 4 CFM 1/3 HP vacuum pump, AC manifold gauge set, 3 color-coded hoses, leak detector, adapters, can taps, vacuum oil, and carry bag for full AC service.
• High-Performance 4 CFM Pump: Single-stage rotary vane vacuum pump delivers fast and deep evacuation, removing moisture before refrigerant charging.
• Durable & Efficient Build: Die-cast aluminum housing with anti-slip base ensures long-lasting use. Built-in cooling fan supports continuous operation.
• Easy Oil Monitoring: Oil sight glass allows quick level checks, while bottom drain port enables clean oil changes.
• Accurate Manifold Gauge Set: Provides precise pressure readings with large viewing glass and shock-resistant design for reliable diagnostics.
• Heavy-Duty Hoses: 3 reinforced 5 ft hoses (red/blue/yellow) ensure leak-proof connections and easy identification.
• Leak Detection Included: Included leak detector helps identify refrigerant leaks for accurate troubleshooting.
• ETL Listed Safety: Certified for safe and reliable operation, giving you confidence during HVAC and AC service work.
• Wide Compatibility: Works with R134a, R410a, R12, R22, R502 systems with included adapters for flexible connections.
• Portable & Professional: Lightweight design with ergonomic handle and carry bag for easy transport and organized storage.

Applications

• Automotive AC Recharge & Repair
• HVAC System Vacuum Pump Operation
• Refrigeration Maintenance
• Leak Detection & Diagnostics
• Home & Commercial AC Service

Technical Specifications

• Power: 1/3 HP (250W)
• Flow Rate: 4 CFM (114 L/min)
• Ultimate Vacuum: 150 Microns / 20 Pa
• Motor Speed: 1440 RPM
• Voltage: 110V / 60Hz
• Duty Cycle: 30 Minutes
• Port Size: 1/4" SAE & 1/2" ACME
• Pump Oil: 0.35 qt / 330 ml Included

Package Includes

• 1 × 4 CFM Single-Stage Vacuum Pump
• 1 × Manifold Gauge Set (±1.6% accuracy)
• 3 × 5 ft Color-Coded Hoses
• 1 × Leak Detector
• 1 × Vacuum Pump Oil (0.35 qt / 330 ml)
• 2 × R410a Adapters (1/4" male to 5/16" female)
• 1 × Adapter (1/4" male to 1/2" female)
• 1 × R134a Self-Sealing Can Tap
• 1 × R134a Puncture Can Tap
• 2 × R134a Quick Couplers
• 1 × Top Pins
• 3 × Sealing Gaskets
• 1 × Portable Carry Bag
• 1 × User Manual

Troubleshooting & FAQ

Pump won’t start or runs unevenly:

• 1. Use stable power and check plug, wiring, capacitor, and switch.
• 2. Keep air intake open and connectors tight.
• 3. Operate between 5–40°C; if rotor is rusted, rotate counterclockwise. High temps may need multiple startups.

Pump does not reach expected vacuum:

• 1. Replace dirty oil and keep it near the middle of the sight glass.
• 2. Check all hoses and interfaces for leaks and ensure sealing rings are intact.
• 3. Clean the exhaust valve if needed.

Oil leaking or spraying:

• 1. Adjust oil level to avoid overfilling and keep the pump level while operating.
• 2. Reattach and clean the oil mist filter.
• 3. Ensure sealing rings and bottom valve are properly installed and tightened.

Gauge inaccurate or hoses leaking:

• 1. Inspect hoses for damage or leaks.
• 2. Tighten connectors or replace sealing rings.
• 3. Adjust or replace the gauge head if readings are inaccurate and check interface fittings.

Leak detector issues:

• 1. Ensure all four batteries are properly installed; replace old batteries if needed.
• 2. Test in a ventilated area using low and high sensitivity.
• 3. Confirm leaks with multiple methods: listen, smell, or use soapy water.

Why Choose This AC Vacuum Pump Kit?
This HVAC vacuum pump kit and AC manifold gauge set combines powerful evacuation performance, accurate diagnostics, and leak detection, making it ideal for HVAC service, refrigerant recharge, automotive AC repair, and air conditioning maintenance.
